Victron Orion XS 1400 (24/12-50A) DC-DC Battery Charger — Bluetooth (24V Alternator → 12V House)
Victron Orion XS 1400 (24/12-50A) DC-DC Battery Charger — Bluetooth (24V Alternator → 12V House)
Regular price
$356.15
Regular price
Sale price
$356.15
Unit price
/
per
Couldn't load pickup availability
The Victron Orion XS 1400 is the 24V-to-12V version of the Orion XS family — takes 24V from a heavy-duty truck or marine alternator and delivers 50A at 12V to your house bank. Same high-efficiency hardware and Bluetooth feature set as the 12/12 XS, but designed for vehicles and boats with 24V starter systems. Often the right pick for medium / heavy-duty trucks, larger marine engines, and commercial chassis builds.
When you need a 24V → 12V DC-DC charger
- Heavy-duty trucks (medium/heavy duty) — most class 6–8 trucks run 24V starter systems and need to charge a 12V house bank for cab accessories or sleeper power
- Larger marine engines — 24V start systems on commercial fishing boats, larger powerboats, and many sailboats
- Commercial chassis builds — buses, school buses, work trucks, military vehicles with 24V electrical systems
- RVs built on commercial chassis — Class A motorhomes on heavy-duty chassis
- Off-grid mobile applications — 24V solar or wind input charging a 12V house bank
Why the Orion XS 1400
- 50A output at 12V — substantial charging power for fast lithium replenishment
- ~95% efficiency — less heat than older 24/12 converters
- Lithium-safe current limiting — protects the alternator from a hungry lithium house bank
- Bluetooth + VictronConnect — monitor and configure from your phone
- VE.Direct port — connect to Cerbo GX for VRM Portal integration
- Three-stage adaptive charging — bulk, absorption, float; lead-acid and LiFePO4 profiles
- Engine-start detection — auto-disables when engine is off
- Wide input voltage range — handles voltage drops during engine start and high charging voltages
- Compact form factor — fits where a 24V → 12V converter previously took up much more room
Specifications
| Input voltage | 24V system (range covers start-system voltage variations) |
|---|---|
| Output voltage | 12V (adjustable) |
| Rated output current | 50A |
| Output power | 700W |
| Efficiency | ~95% |
| Bluetooth | Built-in (VictronConnect) |
| VE.Direct port | Yes |
| Charge stages | Bulk, Absorption, Float (3-stage adaptive) |
| Battery chemistry | Lead-acid (AGM, Gel, Flooded), LiFePO4 |
| Engine-start detection | Yes (adaptive) |
| Protection | Reverse polarity, output short-circuit, over-temperature |
| Operating temperature | -40°C to +60°C |
| Manufacturer SKU | ORI242417040 |
| Warranty | 5 years (manufacturer) |
Recommended applications
- Class 6–8 commercial trucks — cab accessories, sleeper power, refrigerated trailer support
- Commercial marine — 24V engine, 12V house bank
- Bus / coach conversions — 24V chassis with 12V passenger accessories
- Heavy-duty RV chassis — motorhomes on Freightliner, Spartan, or similar 24V chassis
- Mobile commercial — service trucks, mobile workshops, food trucks built on heavy-duty chassis
- Off-grid mobile — surveillance trailers with 24V solar feeding a 12V house bank
Every Jonsson Tech order ships within 5 days nationwide from our Houston, Texas warehouse. Free pre-purchase consultation — call 346-574-9652 or email support@jonssontech.net with your vehicle/vessel specs, alternator size, and battery configuration.
