Victron Energy
Victron MultiPlus Compact 12/2000/80-50 120V VE.Bus Inverter/Charger — UL 458 (Smaller Footprint)
Victron MultiPlus Compact 12/2000/80-50 120V VE.Bus Inverter/Charger — UL 458 (Smaller Footprint)
Couldn't load pickup availability
The Victron MultiPlus Compact 12/2000/80-50 is the space-saving sibling of the standard 12/2000 — same 2000VA pure sine inverter output, same 80A charger, same UL 458 certification, but in a noticeably smaller and lighter enclosure. Designed for installs where every inch matters: tight RV builds, Sprinter conversions, smaller marine berths, and any tight install where the standard MultiPlus won't fit.
Compact vs Standard — which one?
| MultiPlus Compact (this model) | MultiPlus Standard | |
|---|---|---|
| SKU | CMP122200102 | PMP122200102 |
| Inverter output | 2000VA / 1600W | 2000VA / 1600W |
| Charger output | 80A | 80A |
| Transfer switch | 50A | 50A |
| Dimensions | Smaller / lighter | Standard |
| Weight | Lighter (~15 kg vs ~18 kg) | Heavier |
| Price | $904.40 | $861.90 |
Choose Compact if: space is tight (Sprinter conversion, marine cabinet, RV compartment). The smaller footprint is worth the $40 premium.
Choose Standard if: space isn't a concern. Save $40.
What 2000VA powers
Same as the standard 12/2000: small RV air conditioner with PowerAssist, microwave + coffee maker, mid-size refrigerator + lights, power tools on intermittent duty, full home-office equivalent, whole-RV normal living load.
Why the MultiPlus Compact 12/2000/80-50
- Same full 2000VA output — no compromise on capacity
- Smaller, lighter form factor — fits tight installs the standard MultiPlus can't
- 80A multi-stage charger — fast charging from shore or generator
- 50A AC transfer switch — supports 50A RV pedestal
- PowerControl + PowerAssist — boost limited shore (16A, 30A)
- UL 458 certified — legal for mobile and marine use
- VE.Bus networking — parallel or 3-phase capable
- Multi-stage adaptive charging — AGM, Gel, Flooded, LiFePO4 profiles
Specifications
| Nominal DC input voltage | 12V (operating range 9.5–17V) |
|---|---|
| Continuous AC output | 1600W (2000VA) |
| Peak AC output | 4000W (short duration) |
| AC output waveform | Pure sine wave |
| AC output voltage | 120V ± 2%, 60Hz ± 0.1% |
| Charger output current | 80A |
| AC transfer switch | 50A |
| PowerControl / PowerAssist | Yes (16A and 30A pedestal boost) |
| Standards | UL 458 (mobile/marine certified) |
| Networking | VE.Bus (parallel and 3-phase capable) |
| Battery chemistry | AGM, Gel, Flooded, LiFePO4 (configurable) |
| Cooling | Variable-speed temperature-controlled fan |
| Operating temperature | -40°C to +65°C (full power up to 40°C) |
| Manufacturer SKU | CMP122200102 |
| Warranty | 5 years (manufacturer) |
Recommended applications
- Sprinter / Promaster / Transit conversion — where every inch of the electrical compartment matters
- Tight marine installs — sailboat berths and trawler engine room compartments
- Class B / smaller RV — fits where standard MultiPlus is too big
- Tiny home / ADU — minimal mechanical room footprint
- Mobile commercial — tight-package surveillance trailers or food trucks
