Victron Energy

Victron MEGA Fuse 60A/32V — Pack of 5 (DC Battery Circuit Protection)

Victron MEGA Fuse 60A/32V — Pack of 5 (DC Battery Circuit Protection)

$15.30
$15.30
Sale Sold out

The Victron MEGA Fuse 60A is the smallest fuse in the MEGA family — high-current DC battery circuit protection rated to 32V. Sold in a 5-pack for inventory and reliability. Fits any Victron MEGA fuse holder (single or 6-way) and integrates into the Lynx Distributor system.

What size MEGA fuse do I need?

Match the fuse to the cable size and the load. As a guideline:

Circuit Typical fuse
SmartSolar MPPT 75/10, 75/15, 100/15 60A
SmartSolar MPPT 100/20, 100/30 60A–100A
SmartSolar MPPT 100/50, 150/45 80A–125A
Orion-Tr 30A DC-DC charger output 60A
Smaller DC load circuit 60A

The fuse should be sized to protect the smallest gauge cable in the circuit. Always reference your specific product's installation manual for the recommended fuse size.

Why the Victron MEGA Fuse 60A

  • 60A rating at 32V DC — covers most 12V/24V Victron solar and DC-DC charger circuits
  • Quick-blow design — fast response to short circuits
  • Fits Victron MEGA fuse holders — single, 6-way, and Lynx Distributor
  • Robust construction — long-life under continuous current
  • 5-pack value — spare fuses for the install plus future repairs

Specifications

Current rating 60A
Voltage rating 32V DC
Pack quantity 5 fuses
Compatible holders Victron MEGA fuse holders (single, 6-way, Lynx Distributor)
Mounting M8 bolt-down
Manufacturer SKU CIP136060010 (verify with distributor)

Recommended applications

  • SmartSolar MPPT 75V/100V series fusing
  • Orion-Tr 30A DC-DC charger output protection
  • Smaller DC load circuit protection
  • Spare inventory — keep on hand for marine, RV, or off-grid system maintenance

Every Jonsson Tech order ships within 5 days nationwide from our Houston, Texas warehouse.

View full details
