Victron Fuse Holder for MEGA Fuse — Single MEGA Fuse Mount
Victron Fuse Holder for MEGA Fuse — Single MEGA Fuse Mount
Couldn't load pickup availability
The Victron Fuse Holder for MEGA Fuse is the standard single-fuse mount for protecting your main battery cable — a robust molded enclosure with M8 bolts on each side that accepts any MEGA fuse from 60A to 500A. Used for main bank fusing or single high-current circuit protection on inverters, MPPTs, and DC distribution.
Why fuse your main battery cable
An unfused main battery cable is one of the most dangerous failure modes in a DC system. If the positive cable chafes through to ground (against a frame, hose, or sharp edge), it can deliver thousands of amps until either the wire burns through or the battery explodes. A properly sized MEGA fuse interrupts the fault current safely, preventing fire and explosion.
ABYC (marine) and NEC (residential) codes require main bank fusing within 7 inches of the battery positive terminal.
Why the Victron MEGA Fuse Holder
- Accepts MEGA fuses 60A–500A — select the right fuse for your bank size
- M8 bolt connections — standardized, secure cable attachment
- Robust molded enclosure — protects from accidental shorting
- Compact form — fits in tight battery compartment space
- Mountable — secure to a bulkhead or battery box
- Code-compliant — meets ABYC and NEC requirements for main bank protection
Specifications
| Fuse type | MEGA fuse (sold separately) |
|---|---|
| Fuse rating range | 60A–500A MEGA fuses |
| Connection | M8 bolt on each side |
| Voltage rating | 32V DC |
| Construction | Molded enclosure with brass conductors |
| Manufacturer SKU | CIP000100001 |
| Warranty | 5 years (manufacturer) |
Recommended use
- Main battery cable protection — within 7 inches of battery positive terminal
- Inverter input fusing — protect the cable to a MultiPlus or Phoenix Inverter
- MPPT input fusing — protect the cable from MPPT to battery
- DC distribution — single high-current circuit protection
- Marine inspection — required by ABYC for inspection compliance
- Off-grid system code compliance
Need a multi-fuse holder?
For multiple circuits, see the 6-way Fuse Holder for MEGA Fuse (handles 6 separate MEGA-protected circuits in one module).
Every Jonsson Tech order ships within 5 days nationwide from our Houston, Texas warehouse. MEGA fuses sold separately — we stock 60A, 80A, 100A, 125A, 175A, 225A, 400A, 500A.
